C Raymundo Avenue, Pasig City

RICHARD C. FERNANDEZ

Civil – Structural Engineer

Registration No. 0111744

TIN 269-194-269
PTR No. 7360193
Date Issued 15 January 2019
Issued at Makati City
 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY AND AGRICULTURAL DEVELOPMENT CORPORATION
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Job. No.: Design by: CSR Checked by: RCF
Subject: S1 Date: 08/13/18 Rev: -
DESIGN OF ONE WAY SLAB AS PER NSCP 2010
Input

Material Properties:
f'c = 20.70 MPa Concrete Compressive Strength
fy = 275.00 MPa Reinforcing Bar Yield Strength
fyt = 275.00 MPa Temperature Bar Yield Strength
fyd = 550.00 MPa Deck Yield Strength

Metal Deck Properties:

rwt tc
hd = 50 mm hd = deck rib height h
p = 221 mm p = deck rib pitch
hd
rw = 125 mm rw = deck rib bottom width
165 rw
rwt = mm rwt = deck rib top width p td
td = 0.80 mm td = deck thickness
As = 1021.00 mm2 Asd = area of steel deck/m width
Ix = 51.8E+00 mm4 Id = inertia of steel deck/m width
Sp = 23400 mm3 Sp = positive section modulus of steel deck/m width
Sn = 18600 mm3 Sn = negative section modulus of steel deck/m width
tc = 100 mm3 tc = thickness of concrete
wd = 8.00 kg/m2 wd = weight of deck

Slab Properties:
L = 3.20 m Span length
h = 150 mm Total slab thickness
dbm = 10 mm Main reinforcing bar diameter
dbt = 10 mm Temperature bar diameter
2-Span Span Condition

Loading Data:
DL = 3.20 kPa Dead Load (Self Weight)
SD = 2.88 kPa Super Imposed Dead Load
LL = 2.40 kPa Live Load

Output
1. Compute design loads
LC1 = 1.4D + 1.4SD = 8.52 kPa
LC2 = 1.2D + 1.2SD + 1.6LL = 11.14 kPa

Wu = 11.14 kPa

2. Determine design moment

a. Moment @ discontinuous end = 4.75 kN-m
b. Moment @ midspan = 7.99 kN-m
c. Moment @ continuous edge = 14.26 kN-m

3. Moment Capacity of Steel Deck

Fb = 522.50 MPa Fb=0.95fyd
+Mn = 12.23 kN-m +Mn=Fb*Sp
-Mn = 9.72 kN-m -Mn=Fb*Sn

4. Flexural design
a. @ Discontinuous end c. @ Continuous edge
Mu = 0.00 kN-m Mu = 4.54 kN-m
d = 75.00 mm d = 75.00 mm
Rn = 0.00 Mpa Rn = 0.90 Mpa
ρ = 0.0000 ρ = 0.0034
ρ(gross) = 0.0000 ρ(gross) = 0.0017
ρ(min) = 0.0020 ρ(min) = 0.0020
As = 200.00 mm2 As = 200.00 mm2
Sp = 300.00 mm.o.c. Sp = 300.00 mm.o.c.

b. @ Midspan d. For temperature bars

Mu = 0.00 kN-m ρ(temp) = 0.002
d = 75.00 mm As = 157.08 mm2
Rn = 0.00 Mpa Sp = 450.00 mm.o.c.
ρ = 0.0000
ρ(gross) = 0.0000
ρ(min) = 0.0020 Design Summary:
As = 200.00 mm2
Sp = 300.00 mm.o.c. Main Reinforcement:
Steel @ Discontinous Edge: Ø 10 @ 300 mm.o.c.
5. Check shear Steel @ Midspan: Ø 10 @ 300 mm.o.c.
Vu = 22.28 kN Steel @ Continous Edge: Ø 10 @ 300 mm.o.c.
φVc = 42.65 kN
D/C = 0.52 Temperature Bars:
Provide Minimum Reinforcement: Ø 10 @ 450 mm.o.c.

1/14/2019 D:\Files\Projects\C Raymundo\Metal-Deck-Ver.-1.3.xls Page 1

2:14 PM Metal-Deck-Ver.-1.3.xls of 1
 SINGLE-SPAN BEAM ANALYSIS and AISC ASD CODE CHECK
For Simple, Propped, Fixed, or Cantilever Beams
Using AISC 13th Edition (ASD) W, M, HP S, C, or MC Shapes Subjected to X-Axis Bending Only
Project Name: PROPOSED EXPANSION OF OFFICE Client: SANDPIPER SPICES & CONDIMENTS
Project No.: Prep. By: CSR Date: 10/13/2018

Input Data:

Beam Data: c
Span Type? Simple e
Span, L = 15.0000 ft. Simple Beam b
Modulus, E = 29000 ksi a
Inertia, Ix = 348.00 in.^4 Propped Beam +P +M +we
Beam Size = W12X45 +wb
Yield, Fy = 36 ksi Fixed Beam +w
Length, Lb = 15.0000 ft. E,I L
Coef., Cb = 1.00 Cantilever Beam RL x RR
Nomenclature
Beam Loadings:
Full Uniform: Point Loads: a (ft.) P (kips)
w = 0.0450 kips/ft. #1:
Start End #2:
Distributed: b (ft.) wb (kips/ft.) e (ft.) we (kips/ft.) #3:
#1: 0.0000 0.3289 15.0000 0.3289 #4:
#2: 0.0000 0.2960 15.0000 0.2960 #5:
#3: 0.0000 0.2981 15.0000 0.2981 #6:
#4: 0.0000 0.3298 15.0000 0.3298 #7:
#5: 0.0000 0.2960 15.0000 0.2960 #8:
#6: 0.0000 0.2981 15.0000 0.2981 #9:
#7: 0.0000 0.5208 15.0000 0.5208 #10:
#8: #11:
#12:
Moments: c (ft.) M (ft-kips) #13:
#1: #14:
#2: #15:
#3:
#4: AISC Code Check for X-Axis Bending:
Lp = 8.12 ft.
Results: Lr = 29.04 ft.
fbx = 14.11 ksi
End Reactions: Fbx = 21.06 ksi
RL = 18.10 kips RR = 18.10 kips Mrx = 101.26 ft-kips
MxL = N.A. ft-kips MxR = N.A. ft-kips S.R. = 0.670 = fbx/Fbx

Maximum Moments: Nodal Lat. Brcg Requirements:

+Mx(max) = 67.86 ft-kips @x= 7.50 ft. Pbr = 1.41 kips
-Mx(max) = 0.00 ft-kips @x= 0.00 ft. βbr = 7.85 kip / in

Maximum Deflections: AISC Code Check for Gross Shear:

-∆(max) = -0.272 in. @x= 7.50 ft. fv = 4.46 ksi
+∆(max) = 0.000 in. @x= 0.00 ft. Fv = 14.40 ksi
∆(ratio) = L/661 S.R. = 0.310 = fv/Fv

1/14/2019 D:\Files\Projects\C Raymundo\ Page 1

2:10 PM Steel-Beam...xls of 3
 SINGLE-SPAN BEAM ANALYSIS and AISC ASD CODE CHECK
For Simple, Propped, Fixed, or Cantilever Beams
Using AISC 13th Edition (ASD) W, M, HP S, C, or MC Shapes Subjected to X-Axis Bending Only
Project Name: PROPOSED EXPANSION OF OFFICE Client: SANDPIPER SPICES & CONDIMENTS
Project No.: Prep. By: CSR Date: 10/13/2018

Input Data:

Beam Data: c
Span Type? Simple e
Span, L = 9.8500 ft. Simple Beam b
Modulus, E = 29000 ksi a
Inertia, Ix = 156.00 in.^4 Propped Beam +P +M +we
Beam Size = W12X22 +wb
Yield, Fy = 36 ksi Fixed Beam +w
Length, Lb = 9.8500 ft. E,I L
Coef., Cb = 1.00 Cantilever Beam RL x RR
Nomenclature
Beam Loadings:
Full Uniform: Point Loads: a (ft.) P (kips)
w = 0.0220 kips/ft. #1:
Start End #2:
Distributed: b (ft.) wb (kips/ft.) e (ft.) we (kips/ft.) #3:
#1: 0.0000 0.5482 9.8500 0.5482 #4:
#2: 0.0000 0.4934 9.8500 0.4934 #5:
#3: 0.0000 0.4968 9.8500 0.4968 #6:
#4: 0.0000 0.5208 9.8500 0.5208 #7:
#5: #8:
#6: #9:
#7: #10:
#8: #11:
#12:
Moments: c (ft.) M (ft-kips) #13:
#1: #14:
#2: #15:
#3:
#4: AISC Code Check for X-Axis Bending:
Lp = 3.53 ft.
Results: Lr = 11.43 ft.
fbx = 11.92 ksi
End Reactions: Fbx = 17.04 ksi
RL = 10.25 kips RR = 10.25 kips Mrx = 36.07 ft-kips
MxL = N.A. ft-kips MxR = N.A. ft-kips S.R. = 0.700 = fbx/Fbx

Maximum Moments: Nodal Lat. Brcg Requirements:

+Mx(max) = 25.24 ft-kips @x= 4.93 ft. Pbr = 0.51 kips
-Mx(max) = 0.00 ft-kips @x= 0.00 ft. βbr = 4.32 kip / in

Maximum Deflections: AISC Code Check for Gross Shear:

-∆(max) = -0.097 in. @x= 4.93 ft. fv = 3.21 ksi
+∆(max) = 0.000 in. @x= 0.00 ft. Fv = 14.40 ksi
∆(ratio) = L/1214 S.R. = 0.223 = fv/Fv

1/14/2019 D:\Files\Projects\C Raymundo\ Page 2

2:10 PM Steel-Beam...xls of 3
 SINGLE-SPAN BEAM ANALYSIS and AISC ASD CODE CHECK
For Simple, Propped, Fixed, or Cantilever Beams
Using AISC 13th Edition (ASD) W, M, HP S, C, or MC Shapes Subjected to X-Axis Bending Only
Project Name: PROPOSED EXPANSION OF OFFICE Client: SANDPIPER SPICES & CONDIMENTS
Project No.: Prep. By: CSR Date: 10/13/2018

Input Data:

Beam Data: c
Span Type? Simple e
Span, L = 9.8500 ft. Simple Beam b
Modulus, E = 29000 ksi a
Inertia, Ix = 88.60 in.^4 Propped Beam +P +M +we
Beam Size = W12X14 +wb
Yield, Fy = 36 ksi Fixed Beam +w
Length, Lb = 9.8500 ft. E,I L
Coef., Cb = 1.00 Cantilever Beam RL x RR
Nomenclature
Beam Loadings:
Full Uniform: Point Loads: a (ft.) P (kips)
w = 0.0140 kips/ft. #1:
Start End #2:
Distributed: b (ft.) wb (kips/ft.) e (ft.) we (kips/ft.) #3:
#1: 0.0000 0.0857 9.8500 0.0857 #4:
#2: 0.0000 0.1713 9.8500 0.1713 #5:
#3: 0.0000 0.3083 9.8500 0.3083 #6:
#4: 0.0000 0.0942 9.8500 0.0942 #7:
#5: #8:
#6: #9:
#7: #10:
#8: #11:
#12:
Moments: c (ft.) M (ft-kips) #13:
#1: #14:
#2: #15:
#3:
#4: AISC Code Check for X-Axis Bending:
Lp = 3.13 ft.
Results: Lr = 9.34 ft.
fbx = 6.58 ksi
End Reactions: Fbx = 13.78 ksi
RL = 3.32 kips RR = 3.32 kips Mrx = 17.11 ft-kips
MxL = N.A. ft-kips MxR = N.A. ft-kips S.R. = 0.477 = fbx/Fbx

Maximum Moments: Nodal Lat. Brcg Requirements:

+Mx(max) = 8.17 ft-kips @x= 4.93 ft. Pbr = 0.17 kips
-Mx(max) = 0.00 ft-kips @x= 0.00 ft. βbr = 1.42 kip / in

Maximum Deflections: AISC Code Check for Gross Shear:

-∆(max) = -0.056 in. @x= 4.93 ft. fv = 1.39 ksi
+∆(max) = 0.000 in. @x= 0.00 ft. Fv = 14.40 ksi
∆(ratio) = L/2130 S.R. = 0.097 = fv/Fv

1/14/2019 D:\Files\Projects\C Raymundo\ Page 3

2:10 PM Steel-Beam...xls of 3
 "BEAMCOL13.xls" Program
Version 1.3

STEEL BEAM AND COLUMN ANALYSIS / CODE CHECK

Stress Code Check Per AISC 13th Edition Manual (ASD)
For W, S, M, and HP Shapes
Project Name: PROPOSED EXPANSION OF OFFICE Client: SANDPIPER SPICES & CONDIMENTS
Member No.: C1 Prep. By: CSR Date: 10/13/2018

Input Data:

Member Size: Member Properties: Y

Select: W10x88 A= 25.90 in.^2
d = 10.800 in. tf=0.99
Member Loadings: tw = 0.605 in.
P= 38.60 kips bf = 10.300 in.
Mx = 25.24 ft-kips tf = 0.990 in.
My = 45.24 ft-kips k= 1.490 in. d=10.8 X
Ix = 534.00 in.^4
Design Parameters: Sx = 98.50 in.^3 tw=0.605
Fy = 36.00 ksi rx = 4.54 in.
Kx = 1.00 Zx = 113.00 in.^3 bf=10.3
Ky = 1.00 Iy = 179.00 in.^4
Lx = 9.512 ft. Sy = 34.80 in.^3 W10x88 Section
Ly = 9.512 ft. ry = 2.63 in.
Lb = 9.512 ft. Zy = 53.10 in.^3 Shape Factors:
Flex. Type = Single J= 7.530 in.^4 SFx = 1.15
Cb = 1.00 Cw = 4330.0 in.^6 SFy = 1.53

Results:

For Axial Compression: For X-axis Bending: For Y-axis Bending:

Kx*Lx/rx = 25.14 Lp = 10.95 ft. fby = 15.60 ksi
Ky*Ly/ry = 43.40 Lr = 70.51 ft. Fby = 32.89 ksi
Fe = 151.95 rts = 2.99 Mry = 95.39 ft-kips
fa = 1.49 ksi fbx = 3.07 ksi
Fa = 19.52 ksi Fbx = 24.73 ksi
Pa = 505.62 kips Mrx = 202.99 ft-kips

Nodal Lat. Brcg Requirements: Nodal Lat. Brcg Requirements:

Pbr = 0.39 kips Pbr = 0.62 kips
βbr = 5.41 kip / in βbr = 4.70 kip / in

Stress Ratio:
S.R. = 0.637 Eqn. H1-1b <============== S.R. ≤ 1, Member is adequate for loading

Comments:

1/14/2019 D:\Files\Projects\C Raymundo\ Page 1

2:08 PM Steel-Columns.xls of 2
 "BEAMCOL13.xls" Program
Version 1.3

STEEL BEAM AND COLUMN ANALYSIS / CODE CHECK

Stress Code Check Per AISC 13th Edition Manual (ASD)
For W, S, M, and HP Shapes
Project Name: PROPOSED EXPANSION OF OFFICE Client: SANDPIPER SPICES & CONDIMENTS
Member No.: C2 Prep. By: CSR Date: 10/13/2018

Input Data:

Member Size: Member Properties: Y

Select: W8x40 A= 11.70 in.^2
d= 8.250 in. tf=0.56
Member Loadings: tw = 0.360 in.
P= 10.00 kips bf = 8.070 in.
Mx = 15.00 ft-kips tf = 0.560 in.
My = 15.00 ft-kips k= 0.954 in. d=8.25 X
Ix = 146.00 in.^4
Design Parameters: Sx = 35.50 in.^3 tw=0.36
Fy = 36.00 ksi rx = 3.53 in.
Kx = 1.00 Zx = 39.80 in.^3 bf=8.07
Ky = 1.00 Iy = 49.10 in.^4
Lx = 9.512 ft. Sy = 12.20 in.^3 W8x40 Section
Ly = 9.512 ft. ry = 2.04 in.
Lb = 9.512 ft. Zy = 18.50 in.^3 Shape Factors:
Flex. Type = Single J= 1.120 in.^4 SFx = 1.12
Cb = 1.00 Cw = 726.0 in.^6 SFy = 1.52

Results:

For Axial Compression: For X-axis Bending: For Y-axis Bending:

Kx*Lx/rx = 32.34 Lp = 8.49 ft. fby = 14.75 ksi
Ky*Ly/ry = 55.95 Lr = 40.42 ft. Fby = 32.69 ksi
Fe = 91.42 rts = 2.31 Mry = 33.23 ft-kips
fa = 0.85 ksi fbx = 5.07 ksi
Fa = 18.28 ksi Fbx = 23.88 ksi
Pa = 213.89 kips Mrx = 70.64 ft-kips

Nodal Lat. Brcg Requirements: Nodal Lat. Brcg Requirements:

Pbr = 0.10 kips Pbr = 0.47 kips
βbr = 1.40 kip / in βbr = 4.10 kip / in

Stress Ratio:
S.R. = 0.687 Eqn. H1-1b <============== S.R. ≤ 1, Member is adequate for loading

Comments:

1/14/2019 D:\Files\Projects\C Raymundo\ Page 2

2:08 PM Steel-Columns.xls of 2
 RCF Col v1.0 .
Project: Proposed Expansion of North South Realty
Location: 255 C Raymundo, Pasig City
Client: Sandpiper Spices & Condiments Corporation
Checked
Job No.: Calc. by: RCF
by:
Subject: PEDESTAL P1 Date: 15-Oct-19 Revision: -
DESIGN OF RC COLUMN AS PER ACI 318-14

INPUT DATA Y
MATERIAL PROPERTIES
'
fc = 20.7 Mpa CONCRETE STRENGTH 0.8 fcu
fy = 276 Mpa REBAR YIELD STRESS
fyt = 276 Mpa TIES YIELD STRESS
Es = 200,000 Mpa MODULUS OF ELASTICITY OF STEEL
Ec = 21,384 Mpa MODULUS OF ELASTICITY OF CONCRETE X

εc = 0.003 MAXIMUM CONCRETE STRAIN

εs = Infinity MAXIMUM STEEL STRAIN

TRANSVERSE REBAR TYPE Ties

CROSS-SECTION SHAPE TRANSFORMED PROPERTIES

Cx = 350 mm WIDTH Ag = 122,500 mm2
Cy = 350 mm HEIGHT Ix = 1.25E+09 mm4
Cc = 38 mm CONCRETE COVER Iy = 1.25E+09 mm4

REBARS REBAR SUMMARY

2
Corner Along X Along Y Ties Spacing Σ(As) = 2,513.27 mm
no. mm no. mm no. mm mm mm ρg = 2.052%
4 Ø 20 2 Ø 20 2 Ø 20 Ø 12 100 No. of bars = 8

REBAR PROPERTIES
Rebar Area Coordinates
Bar No. Designation
mm2 X Y
1 20d 314.1593 137.00 290.00
2 20d 314.1593 137.00 60.00
3 20d 314.1593 -137.00 290.00
4 20d 314.1593 -137.00 60.00
5 20d 314.1593 0.00 60.00
6 20d 314.1593 0.00 290.00
7 20d 314.1593 137.00 175.00
8 20d 314.1593 -137.00 175.00

Page 1 of 2 Spreadsheet by: Engr. Richard C. Fernandez

 RCF Col v1.0 .

Axial Force/Bending Moment

Interaction Diagram @ X-axis
2,000
φPn

1,500

1,000

500
-119.14 119.14

0
-150 -100 -50 0 50 100 φMn 150

-500

-1,000

Pu Mux-Top Muy-Top Mux-Bot Muy-Bot D/C D/C

No. L/C Remarks
kN kN-m kN-m kN-m kN-m Top Bot
1 USD202 233.20 0.00 0.00 0.00 0.00 0.16 0.16 Passed!

Page 2 of 2 Spreadsheet by: Engr. Richard C. Fernandez

 RCF Col v1.0 .
Project: Proposed Expansion of North South Realty
Location: 255 C Raymundo, Pasig City
Client: Sandpiper Spices & Condiments Corporation
Checked
Job No.: Calc. by: RCF
by:
Subject: PEDESTAL P2 Date: 15-Oct-19 Revision: -
DESIGN OF RC COLUMN AS PER ACI 318-14

INPUT DATA Y
MATERIAL PROPERTIES
'
fc = 20.7 Mpa CONCRETE STRENGTH 0.8 fcu
fy = 276 Mpa REBAR YIELD STRESS
fyt = 276 Mpa TIES YIELD STRESS
Es = 200,000 Mpa MODULUS OF ELASTICITY OF STEEL
Ec = 21,384 Mpa MODULUS OF ELASTICITY OF CONCRETE X
εc = 0.003 MAXIMUM CONCRETE STRAIN
εs = Infinity MAXIMUM STEEL STRAIN

TRANSVERSE REBAR TYPE Ties

CROSS-SECTION SHAPE TRANSFORMED PROPERTIES

Cx = 275 mm WIDTH Ag = 75,625 mm2
Cy = 275 mm HEIGHT Ix = 4.77E+08 mm4
Cc = 38 mm CONCRETE COVER Iy = 4.77E+08 mm4

REBARS REBAR SUMMARY

2
Corner Along X Along Y Ties Spacing Σ(As) = 1,608.50 mm
no. mm no. mm no. mm mm mm ρg = 2.127%
4 Ø 16 2 Ø 16 2 Ø 16 Ø 10 100 No. of bars = 8

REBAR PROPERTIES
Rebar Area Coordinates
Bar No. Designation
mm2 X Y
1 16d 201.0619 99.50 219.00
2 16d 201.0619 99.50 56.00
3 16d 201.0619 -99.50 219.00
4 16d 201.0619 -99.50 56.00
5 16d 201.0619 0.00 56.00
6 16d 201.0619 0.00 219.00
7 16d 201.0619 99.50 137.50
8 16d 201.0619 -99.50 137.50

Page 1 of 2 Spreadsheet by: Engr. Richard C. Fernandez

 RCF Col v1.0 .

Axial Force/Bending Moment

Interaction Diagram @ X-axis
1,000
φPn
800

600

400
-52.11 52.11
200

0
-60 -40 -20 0 20 40 60
φMn
-200

-400

-600

Pu Mux-Top Muy-Top Mux-Bot Muy-Bot D/C D/C

No. L/C Remarks
kN kN-m kN-m kN-m kN-m Top Bot
1 USD202 36.30 0.00 0.00 0.00 0.00 0.04 0.04 Passed!

Page 2 of 2 Spreadsheet by: Engr. Richard C. Fernandez

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY AND DEVELOPMENT CORP.
Location: 255 C RAYMUNDO AVE. PASIG CITY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Job No.: Calc. by: CSR Checked by: RCF
Subject: LC100x50x15x1.2 Date: 13-Oct-18 Revision: -
DESIGN OF PURLINS AS PER AISI AND ASD

INPUT DATA
MATERIAL PROPERTIES TRIAL SECTION
Fy = 248.00 MPa Steel Yield Strength Select: LC 100x50x15x1.2
E = 203,395 MPa Steel Modulus of Elasticity
Fu = 248.00 MPa Sag rod Tensile Strength MEMBER PROPERTIES
H = 100.0 mm
GEOMETRY AND DIMENSIONS B = 50.0 mm
L = 3.20 m Truss Spacing D = 15.0 mm
S = 0.60 m Purlin Spacing t = 1.2 mm
α = 4.00 deg. Roof Slope R = 2.4 mm
np = 8 No. of purlin considered
ns = 2 No. of Lines of Sag Rod
ds = 10 mm Diameter of Sag rod B
w 3
2 2
LOADING DATA R d D
DEAD LOADS: 1
Sheathing/Acces. = 200.00 Pa t
Wt. of Purlins = 2.08 kg/m c
4 r
H h
LIVE LOAD:
Roof live load = 1,000.00 Pa

WIND PRESSURE: 7
Uplift pressure = 1826.00 Pa
6 6
Normal pressure = 45.00 Pa 5
Purlin section with elements:
a) cross section
b) line element model

OUTPUT DATA
I.Properties of 90° corner (Elements 2 and 6)
r = 3.00 mm Corner radius
u = 4.71 mm Length of arc
c = 1.91 mm Distance of centroidal from center of radius
I'c = 4.02 mm3 I' of corner about its own centroidal axis

II. Nominal flexural strength (Mn) (Section C3.1.1)

A. Computation of Ix assuming web is fully effective
Assume f = Fy in the top fibers of the section.

Element 4: Web Element Full Depth When Assumed Fully Effective

h = 92.8 mm
h/t = 77.333 < 200, OK!, Sec. B1.2(a)

Element 1: Compression Lip

Section B3.1 Uniformly compressed unstiffened element
d = 11.40 mm d = D-(R + t}
ku = 0.43 k u = 0.43
λ = 0.53 λ = (1.052/sqrt(ku))(d/t)(sqrt(f/E)
< 0.673, d's = d
ρ = N.A. ρ = (1-(0.22/ψ))/ψ
d's = 11.40 mm
4
Is = 148.15 mm Is = d3t/12

Element 3: Flange Flat

w = 42.800 mm
w/t = 35.667 < 60, OK! Clause Bl.l(a)(l)
S = 36.657 S = 1.28*sqrt(E/Fy) Eq. B4-1
S/3 = 12.219 S/3 < w/t < S
Ia = 222.13 mm4 min of 399t^4(((w/t)/S)-(sqrt(ku/4)))^3
t^4((115(w/t)/S)+5)
n = 0.339 n = (0.582-(w/t)/4S)>=1/3

Calculate buckling coefficients (k) and stiffener reduced effective width (ds):
ka = 3.50 ka = 5.25 -5(D/w) Eq. B4.2-8
C2 = 0.67 C2 = Is/Ia <= 1.0 Eq. B4.2-5
C1 = 1.33 C1 = 2 - C2 Eq. B4.2-6
n
k = 3.10 k = C2 (ka - ku)+ku Eq. B4.2-7
ds = 7.60 mm ds = C2d's Eq. B4.2-9

Section B2.1(a) Effective width of flange element 3 for load capacity

λ = 0.74 λ = (1.052/sqrt(ku))(w/t)(sqrt(f/E)
> 0.673, calculate rho
ρ = 0.74 ρ = (1-(0.22/ψ))/ψ
bf = 40.53 mm bf = ρw

Developed by: Engr. Richard C. Fernandez Page 1 of 3 Purlins_v1.0.xls

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY AND DEVELOPMENT CORP.
Location: 255 C RAYMUNDO AVE. PASIG CITY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Job No.: Calc. by: CSR Checked by: RCF
Subject: LC100x50x15x1.2 Date: 13-Oct-18 Revision: -
DESIGN OF PURLINS AS PER AISI AND ASD

Calculate second moment of area of effective section

Li is the effective length of all elements of type i, and yi is the distance from the top fiber:

Element Effective 2
yi Liyi Liyi2 I' Liycg
no. length, Li 2 3
i (mm)
(mm) (mm ) (mm3) (mm ) (mm3)
1 7.60 7.40 56.28 4.17E+02 3.66E+01 1.99E+04
2 9.42 1.69 15.91 26.87 8.05 2.47E+04
3 40.53 0.60 24.32 14.59 0.00 1.06E+05
4 92.80 50.00 4,640.00 232.00E+03 66,598.23 2.43E+05
5 42.80 99.40 4,254.32 422.88E+03 0.00 1.12E+05
6 9.42 98.31 926.09 91,044.80 8.05 2.47E+04
7 11.40 90.70 1,033.98 93,781.99 123.46 2.99E+04
Sum 213.97 348.10 10,950.89 840.16E+03 6.68E+04 560.46E+03

Determine ycg from top fiber: w

ycg = 51.18 mm C1b/2 3 C2b/2 2
2
f f
ILy2 = 560.5E+03 mm
3
f1 D f3
I'x = 346.5E+03 3 R
mm b1 c ds d
Ix = 415.8E+03 mm4 1
4
Sex = 8.12E+03 mm3 ycg

B. Check Web (Section B2.3) b2 8

f1 = 230.555 MPa
f2 = -219.128 MPa 9
ψ = -0.950 7
5
k = 22.741
f2
λ = 0.574
< 0.673, d's = d 6
ρ = N.A. 6 B
be = 99.68 mm
b1 = 25.23 mm Bending stress with effective widths
b2 = 49.84 mm
bcw = 47.58 mm
b1+b2 = 75.07 mm > bcw47.58 mm, be = 75.07 mm

C. Iterate on web effective width

Try a value of the centroid position and iterate until convergence:

ycg = 48.216 mm ycg(new) = 48.216 mm ==> O.K.

D. Check Web (Section B2.3)

f1 = 229.483 MPa
f2 = -247.835 MPa
ψ = -1.080 ψ = f2/f1 Eq. B2.3-5
k = 26.157 k = 4+2(1-ψ)3+2(1-ψ) Eq. B2.3-4
λ = 0.534 λ = (1.052/sqrt(ku))(h/t)(sqrt(f/E)
< 0.673, d's = d
ρ = N.A. mm ρ = (1-(0.22/ψ))/ψ Eq. B2.1-3
be = 102.17 mm be = ρh Eq. B2.1-2
b1 = 25.04 mm b1 = be/(3-ψ) Eq. B2.3-1
b2 = 51.08 mm b2 = be/2 if y < -0.236
b2 = be-b1 if y > -0.237

Element Effective
yi Liyi Liyi2 I' Liycg2
no. length, Li
i (mm)
(mm) (mm2) (mm3) (mm3) (mm3)
1 7.60 7.40 56.28 4.17E+02 3.66E+01 1.63E+04
2 9.42 1.69 15.91 26.87 8.05 2.02E+04
3 40.53 0.60 24.32 14.59 0.00 8.67E+04
4 25.04 16.12 403.69 6,507.83 1,308.60 5.36E+04
5 42.80 99.40 4,254.32 422.88E+03 0.00 9.16E+04
6 9.42 98.31 926.09 91,044.80 8.05 2.02E+04
7 11.40 90.70 1,033.98 93,781.99 123.46 2.44E+04
8 51.08 22.67 1,158.28 26,262.47 217.47 1.09E+05
9 48.18 72.31 3,484.09 251.93E+03 9,322.39 103.13E+03

ycg = 46.264 mm
ILy2 = 525.4E+03 mm
3

I'x = 378.5E+03 mm3

Ix = 454.2E+03 mm4

E. Calculation of effective section modulus (Sex) for compression flange stressed to yield
Sex = 9.82E+03 mm3 Sex = Ix/ycg Effective section modulus
Mn = 2.43 kN-m Mn = SexFy Nominal flexural strength
Md = 1.46 kN-m Md = Mn/Ω Design flexural strength

Developed by: Engr. Richard C. Fernandez Page 2 of 3 Purlins_v1.0.xls

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY AND DEVELOPMENT CORP.
Location: 255 C RAYMUNDO AVE. PASIG CITY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Job No.: Calc. by: CSR Checked by: RCF
Subject: LC100x50x15x1.2 Date: 13-Oct-18 Revision: -
DESIGN OF PURLINS AS PER AISI AND ASD
III. Design Stress under Uplift and Gravity Loadings
A. Strength for Bending Alone Braced by Sheathing
DL = 0.14 kN/m ASD101 = DL + LL = 0.74 kN/m M = 0.95 kN-m
LL = 0.60 kN/m ASD102 = DL + Wp = 0.17 kN/m M = 0.21 kN-m
Wn = 1.10 kN/m ASD103 = DL - Wn = -0.96 kN/m M = -1.22 kN-m
Wp = 0.03 kN/m

1. Under Uplift Force

M = 1.22 kN-m < Md = 1.46 kN-m ==> O.K.

2. Under Gravity Loading

M = 0.95 kN-m < Md = 1.46 kN-m ==> O.K.

B. Strength for Shear Alone

DL = 0.14 kN/m ASD101 = DL + LL = 0.74 kN/m V = 1.18 kN
LL = 0.60 kN/m ASD102 = DL + Wp = 0.17 kN/m V = 0.27 kN
Wn = 1.10 kN/m ASD103 = DL - Wn = -0.96 kN/m V = -1.53 kN
Wp = 0.03 kN/m

kv = 5.34 For Unreinforced web

h = 92.80 mm h = H - 2(R+t)
h/t = 77.33

= 66.18 Since, h/t < 1.415 = 93.64

Then,
0.905 N.A.
= kN
ℎ

0.64 = 15.13 kN

1. Under Uplift Force

V = 1.53 kN < Vd = 9.06 kN-m ==> O.K.

2. Under Gravity Loading

V = 1.18 kN < Vd = 9.06 kN-m ==> O.K.

IV. Design of Sagrod

A. Sagrods at Midspan
Wt = N.A. Pa
Rsag = N.A. N Rsag = (5/8)(Wt)Lsinα
ΣR = N.A. N ΣR = (# of purlins)(Rsag)
Ft = N.A. Mpa Ft = 0.33Fu
As = N.A. mm2 As = Rsag/Ft

As(used = N.A. mm2 > As = N.A. mm2

B. Sagrods at Third Points

Wt = 573.14 Pa
Rsag = 46.91 N Rsag = (11/30)(Wt)Lsinα
ΣR = 375.28 N ΣR = (# of purlins)(Rsag)
Ft = 81.84 Mpa Ft = 0.33Fu
4.59 2
As = mm As = Rsag/Ft

78.54 2 > 4.59 2

As(used = mm As = mm ==> O.K.

Developed by: Engr. Richard C. Fernandez Page 3 of 3 Purlins_v1.0.xls

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: CSR Checked by: RCF
Subject: F1 Rev: -
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97

+Y
Input Data:
3 2
Material Properties:
Conc. Comp. Strength, fc'= 20.70 Mpa L/2
Reinf. Yeild Strength, fy= 276.00 Mpa
Concrete Unit Wt., γc= 23.54 kN/m^3
+X
Lcy B
Soil Properties:
Allow. Soil Pressure, SBC = 72.00 kPa Lcx B/2
Soil Unit Weight, γs = 18.00 kPa
Depth of Trench, D = 1.20 m
4 L 1
Footing Info:
Footing Length, L = 1700 mm
Footing Plan
Footing Width, B = 1600 mm
Footing Thickness, T = 250 mm
Clear Cover, Cc = 75 mm
Reinforcing Bar Diameter = 16 mm Pu

Column Info: Edge

Column Length, Lcx= 350 mm
Q
Column Width, Lcy= 350 mm
Location along X= 0 mm
Location along Y= 625 mm Lcx h
Ph
Loading Data: D
Service Dead Load, D= 121.00 kN (Working) T
Service Live Load, L= 55.00 kN (Working)
Service Surcharge, Q= 50.00 kPa
q
Earthquake Axial Load, Eh= 50.00 kN (Working)
Wind Axial Load, W = 0.00 kN (Working) L

Nomenclature
Seismic Parameters:
Rho, ρ = 1.00 (from ETABS, 1.0 default)
Seismic Coefficient, Ca = (Table 16-Q UBC'97)
Importance Factor, I = 1.00 (Table 16-K UBC'97)
Therefore, E = 50.00 kN (Ultimate)
Therefore, E = 50.00 kN (Service)

Where:
E = ρEh + 0.50CaID ===> Ultimate
E = ρEh ===> Service

Service Load Combinations:

ASD101: D + L = 176.00 kN (governs)
ASD102: D + W = 121.00 kN
ASD103: D + E/1.4 = 156.71 kN
ASD104: D + 0.75(L + E/1.4) = 189.04 kN (neglect)
ASD105: 0.60D + E/1.4 = 108.31 kN (neglect)
ASD106: D + L + E/1.4 = 211.71 kN (neglect)
ASD107: D + 0.75(L +W) = 162.25 kN (neglect)
ASD108: 0.60D + W = 72.60 kN (neglect)
ASD109: D + L + W = 176.00 kN (neglect)

Page 1 of 7 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: CSR Checked by: RCF
Subject: F1 Rev: -
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97
Ultimate Load Combinations:
USD201: 1.4D = 169.40 kN
USD202: 1.2D + 1.6L = 233.20 kN (governs)
USD203: 1.2D + 0.80W = 145.20 kN
USD204: 0.90D + 1.6W = 108.90 kN
USD205: 1.2D + 1.6W + 0.5L = 172.70 kN
USD206: 1.2D + 1.0E + 0.5L = 222.70 kN
USD207: 0.90D + 1.0E = 158.90 kN

Design Procedure:

Check Soil Bearing Capacity:

Column Working Load, Rv = 176.00 kN
Working Bearing Pressure, qv = 64.71 kPa
Demand-Capacity Ratio, D/C = 0.90 < 1, …OK (Footing is adequate to carry the loadings)

Applied Ultimate Soil Bearing Pressure:

Ultimate Axial Load, Pu = 233.20 kN
Ultimate Bearing Pressure, qu = 85.74 kPa

Design Checks: c1+d

1. Wide-beam action along L-Direction
Vu = qs x tributary area
= 68.59 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 162.43 kN > Vu = 68.59 kN O.K.
2. Wide-beam action along B-Direction
Vu = qs x tributary area bw c2+d c2
= 65.59 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 172.58 kN > Vu = 65.59 kN O.K.
2. Two-way action (Punching Shear)
Vu = qs x tributary area
=208.77 kN
φVc = φ0.17(1+(2/β))λ√fc'bod (ACI 318-08 Eq. (11-31))
= 639.55 kN
φVc = φ0.083(((αsd)/bo)+2)√fc'bod (ACI 318-08 Eq. (11-32)) Tributary area for two-way action shear
= 468.38 kN
φVc = φ0.33λfc'^1/2*bod (ACI 318-08 Eq. (11-33)) Tributary area for wide-beam action shear
= 413.83 kN governs > Vu = 208.77 kN O.K.

Design for Reinforcement:

1. For L-Direction 2. For B-Direction
Mu = 31.25 kN-m Mu = 113.87 kN-m
a= 5.91 mm a= 31.54 mm
β1 = 0.85 (ACI 318-08 Sec.10.2.7.3) β1 = 0.85 (ACI 318-08 Sec.10.2.7.3)
c= 6.96 mm c= 37.10 mm
εt = 0.0725 >= 0.004, Tension-controlled εt = 0.0111 >= 0.004, Tension-controlled
φ= 0.90 (ACI 318-08 Sec. 9.3.2) φ= 0.90 (ACI 318-08 Sec. 9.3.2)
Rn = 0.71 Mpa Rn = 2.43 Mpa
ρ = 0.00262 ρ = 0.00951
ρ(gross area) = 0.00183 < rho(min), use rho(min) ρ(gross area) = 0.00666 > rho(min) O.K.
ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4) ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4)
As = 560.00 mm^2 As = 2830.69 mm^2

Page 2 of 7 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: CSR Checked by: RCF
Subject: F1 Rev: -
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97

Critical Section of Bending Along L-Direction Critical Section for Bending Along B-Direction

Design Summary:

Note: Maximum bar spacing (s), must not exceed 450mm (ACI 318-08 Sec.15.10.4).

Footing Plan

Footing Size:
Use 1.60 m x 1.70 m x 0.25 m Footing Dimension.
Reinforcements:
Use 5 pcs 16 mm diam. RSB for Long Direction.
Use 16 pcs 16 mm diam. RSB for Short Direction

Page 3 of 7 Developed by: Engr. Richard C. Fernandez

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C RAYMUNDO AVE. PASIG CITY
Job. No.: Design by: CSR Checked by: RCF
Subject: F2 Date: 10/14/18 Rev: -
DESIGN OF ISOLATED FOOTING
Input:
Y
Material Properties
f'c = 3,000 psi Concrete yield strength
fy = 40,000 psi Reinforcing steel yield strength

Column Dimension Cx

Bars along W
Cx = 350 mm Col. dimension along X direction
Cy = 350 mm Col. dimension along Y direction X Cy W

Soil Properties
Bars along L
SBC = 75.00 kPa Safe Bearing Capacity

Footing Geometry
L = 1600 mm Footing length
L
W = 1600 mm Footing width
T = 250 mm Footing thickness
Cc = 75 mm Concrete cover NSCP 2015 Requirements:
rho = 1.00 Redundancy factor
Reinforcement Details Ca = Siesmic coefficient
Øx = 16 mm Bar dia. along L direction I = 1.00 Importance factor
Øy = 16 mm Bar dia. along W direction
where:
Axial Loads (Service Condition) E = ρEQ + 0.5CaIDa for ASD102 - ASD104
DL = 121.00 kN Axial dead load for USD203 & USD204
LL = 55.00 kN Axial live load
EQ = 50.00 kN Axial seismic load E = ρEQ - 0.5CaIDa for ASD105
Wind = 50.00 kN Axial wind Load for USD205 & USD207

Output:

Check footing size requirements

Service Load Combination
ASD101 = 1.0DL + 1.0LL = 176.00 kN
ASD102 = 1.00DL + 0.75LL + 0.525E = 188.50 kN ===>governs!
ASD103 = 1.00DL + 0.75LL - 0.525E = 136.00 kN
ASD104 = 1.00DL + 0.70E = 156.00 kN
ASD105 = 0.60DL + 0.70E = 107.60 kN
ASD106 = 1.0DL + 0.75LL + 0.45Wind = 184.75 kN
ASD107 = 1.0DL + 0.75LL - 0.45Wind = 139.75 kN
ASD108 = 1.0DL + 0.6Wind = 151.00 kN
ASD109 = 0.6DL + 0.6Wind = 102.60 kN

Rv = 188.50 kN Column service load

qs = 73.63 kPa Service bearing presure
d/c = 0.98 < 1, …OK (Footing is adequate to carry the loadings)

Check footing strength requirements

Ultimate Load Combination
USD201 = 1.4DL = 169.40 kN
USD202 = 1.2DL + 1.6LL = 233.20 kN ===>governs!
USD203 = 1.200DL + 0.5LL + 1.00E = 222.70 kN
USD204 = 1.200DL + 0.5LL - 1.00E = 122.70 kN
USD205 = 0.900DL + 1.00E = 158.90 kN
USD206 = 0.900DL - 1.00E = 58.90 kN
USD207 = 1.2DL + 0.50LL + 1.0Wind = 222.70 kN
USD208 = 1.2DL + 0.50LL - 1.0Wind = 122.70 kN
USD209 = 0.9DL + 1.0Wind = 158.90 kN
USD210 = 0.9DL - 1.0Wind = 58.90 kN

Pu = 233.20 kN Ultimate axial load

qu = 91.09 kPa Ultimate bearing pressure

Developed by: Engr. Richard C. Fernandez F2 Page 4 of 7

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C RAYMUNDO AVE. PASIG CITY
Job. No.: Design by: CSR Checked by: RCF
Subject: F2 Date: 10/14/18 Rev: -
DESIGN OF ISOLATED FOOTING

A. Shear Adequacy Checks

c1+d
1. Wide-beam action along X-direction
Vu = qu x tributary area
= 66.75 kN
φVc = φ0.17sqrt(f'c)bwd
= 154.94 kN > Vu = 66.75 kN ok!
2. Wide-beam action along Y-direction
Vu = qu x tributary area bw c2+d c2
= 69.09 kN
φVc = φ0.17sqrt(f'c)bwd
= 140.10 kN > Vu = 69.09 kN ok!
3. Two-way action (Punching Shear)
Vu = qu x tributary area
= 210.34 kN
φVc = φ0.17(1+(2/β))λ√fc'bod
= 582.19 kN d c1
φVc = φ0.083(((αsd)/bo)+2)√fc'bod Tributary area for two-way action shear
= 505.33 kN
φVc = φ0.33λfc'^1/2*bod Tributary area for wide-beam action shear
= 376.71 kN governs > Vu = 210.34 kN ok!

B. Design for Reinforcement

1. For X-direction (Reinf. Along L) 2. For Y-direction (Reinf. Along W)

Critical Section of Bending Critical Section of Bending

Mu = 28.47 kN-m Mu = 28.47 kN-m

a = 5.92 mm a = 5.92 mm
β1 = 0.85 β1 = 0.85
c = 6.96 mm c = 6.96 mm
εt = 0.0690 >=0.004, Tension-controlled εt = 0.0621 >=0.004, Tension-controlled
φ = 0.90 φ = 0.90
Rn = 0.7088 Mpa Rn = 0.8670 Mpa
ρ = 0.00262 ρ = 0.00322
ρ(gross area) = 0.00175 < rho(min), use rho(min) ρ(gross area) = 0.00195 < rho(min), use rho(min)
ρ(min) = 0.00200 ρ(min) = 0.00200
As(required) = 534.40 mm^2 As(required) = 483.20 mm^2

Design Summary
Footing size:
Use 1.60m x 1.60m x0.25m Footing Dimension
Reinforcements:
Use 5-16mm Bottom Bars along L (BB1) Spacing: 342.50 mm.o.c.
Use 5-16mm Bottom Bars along W (BB2) Spacing: 342.50 mm.o.c.

Note: Maximum bar spacing (s), must not exceed minimum of 2T & 450mm (ACI 318-14 Sec.8.7.2.2).

Developed by: Engr. Richard C. Fernandez F2 Page 5 of 7

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C RAYMUNDO AVE. PASIG CITY
Job. No.: Design by: CSR Checked by: RCF
Subject: F3 Date: 10/14/18 Rev: -
DESIGN OF ISOLATED FOOTING
Input:
Y
Material Properties
f'c = 3,000 psi Concrete yield strength
fy = 40,000 psi Reinforcing steel yield strength

Column Dimension Cx

Bars along W
Cx = 350 mm Col. dimension along X direction
Cy = 350 mm Col. dimension along Y direction X Cy W

Soil Properties
Bars along L
SBC = 75.00 kPa Safe Bearing Capacity

Footing Geometry
L = 800 mm Footing length
L
W = 800 mm Footing width
T = 200 mm Footing thickness
Cc = 75 mm Concrete cover NSCP 2015 Requirements:
rho = 1.00 Redundancy factor
Reinforcement Details Ca = Siesmic coefficient
Øx = 16 mm Bar dia. along L direction I = 1.00 Importance factor
Øy = 16 mm Bar dia. along W direction
where:
Axial Loads (Service Condition) E = ρEQ + 0.5CaIDa for ASD102 - ASD104
DL = 14.00 kN Axial dead load for USD203 & USD204
LL = 9.00 kN Axial live load
EQ = 15.00 kN Axial seismic load E = ρEQ - 0.5CaIDa for ASD105
Wind = 15.00 kN Axial wind Load for USD205 & USD207

Output:

Check footing size requirements

Service Load Combination
ASD101 = 1.0DL + 1.0LL = 23.00 kN
ASD102 = 1.00DL + 0.75LL + 0.525E = 28.63 kN ===>governs!
ASD103 = 1.00DL + 0.75LL - 0.525E = 12.88 kN
ASD104 = 1.00DL + 0.70E = 24.50 kN
ASD105 = 0.60DL + 0.70E = 18.90 kN
ASD106 = 1.0DL + 0.75LL + 0.45Wind = 27.50 kN
ASD107 = 1.0DL + 0.75LL - 0.45Wind = 14.00 kN
ASD108 = 1.0DL + 0.6Wind = 23.00 kN
ASD109 = 0.6DL + 0.6Wind = 17.40 kN

Rv = 28.63 kN Column service load

qs = 44.73 kPa Service bearing presure
d/c = 0.60 < 1, …OK (Footing is adequate to carry the loadings)

Check footing strength requirements

Ultimate Load Combination
USD201 = 1.4DL = 19.60 kN
USD202 = 1.2DL + 1.6LL = 31.20 kN
USD203 = 1.200DL + 0.5LL + 1.00E = 36.30 kN ===>governs!
USD204 = 1.200DL + 0.5LL - 1.00E = 6.30 kN
USD205 = 0.900DL + 1.00E = 27.60 kN
USD206 = 0.900DL - 1.00E = -2.40 kN
USD207 = 1.2DL + 0.50LL + 1.0Wind = 36.30 kN ===>governs!
USD208 = 1.2DL + 0.50LL - 1.0Wind = 6.30 kN
USD209 = 0.9DL + 1.0Wind = 27.60 kN
USD210 = 0.9DL - 1.0Wind = -2.40 kN

Pu = 36.30 kN Ultimate axial load

qu = 56.72 kPa Ultimate bearing pressure

Developed by: Engr. Richard C. Fernandez F3 Page 6 of 7

 Project: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C RAYMUNDO AVE. PASIG CITY
Job. No.: Design by: CSR Checked by: RCF
Subject: F3 Date: 10/14/18 Rev: -
DESIGN OF ISOLATED FOOTING

A. Shear Adequacy Checks

c1+d
1. Wide-beam action along X-direction
Vu = qu x tributary area
= 4.90 kN
φVc = φ0.17sqrt(f'c)bwd
= 54.28 kN > Vu = 4.90 kN ok!
2. Wide-beam action along Y-direction
Vu = qu x tributary area bw c2+d c2
= 5.63 kN
φVc = φ0.17sqrt(f'c)bwd
= 46.85 kN > Vu = 5.63 kN ok!
3. Two-way action (Punching Shear)
Vu = qu x tributary area
= 24.76 kN
φVc = φ0.17(1+(2/β))λ√fc'bod
= 367.18 kN d c1
φVc = φ0.083(((αsd)/bo)+2)√fc'bod Tributary area for two-way action shear
= 274.53 kN
φVc = φ0.33λfc'^1/2*bod Tributary area for wide-beam action shear
= 237.58 kN governs > Vu = 24.76 kN ok!

B. Design for Reinforcement

1. For X-direction (Reinf. Along L) 2. For Y-direction (Reinf. Along W)

Critical Section of Bending Critical Section of Bending

Mu = 1.15 kN-m Mu = 1.15 kN-m

a = 3.95 mm a = 3.95 mm
β1 = 0.85 β1 = 0.85
c = 4.64 mm c = 4.64 mm
εt = 0.0726 >=0.004, Tension-controlled εt = 0.0623 >=0.004, Tension-controlled
φ = 0.90 φ = 0.90
Rn = 0.1165 Mpa Rn = 0.1564 Mpa
ρ = 0.00042 ρ = 0.00057
ρ(gross area) = 0.00025 < rho(min), use rho(min) ρ(gross area) = 0.00029 < rho(min), use rho(min)
ρ(min) = 0.00200 ρ(min) = 0.00200
As(required) = 187.20 mm^2 As(required) = 161.60 mm^2

Design Summary
Footing size:
Use 0.80m x 0.80m x0.20m Footing Dimension
Reinforcements:
Use 3-16mm Bottom Bars along L (BB1) Spacing: 301.00 mm.o.c.
Use 3-16mm Bottom Bars along W (BB2) Spacing: 301.00 mm.o.c.

Note: Maximum bar spacing (s), must not exceed minimum of 2T & 450mm (ACI 318-14 Sec.8.7.2.2).

Developed by: Engr. Richard C. Fernandez F3 Page 7 of 7

 C_Raymundo_driveway.sdb SAP2000 v20.0.0
1. Material properties 18 October 2018

1. Material properties
This section provides material property information for materials used in the model.

Table 1: Material Properties 02 - Basic Mechanical Properties

Table 1: Material Properties 02 - Basic Mechanical Properties
UnitWeight UnitMass E1 G12 A1
Material U12
KN/m3 KN-s2/m4 KN/m2 KN/m2 1/C
3000Psi 2.3563E+01 2.4028E+00 21525562.37 8968984.32 0.2 9.9000E-06
A36 7.6973E+01 7.8490E+00 199947978.8 76903068.77 0.3 1.1700E-05
A615Gr40 7.6973E+01 7.8490E+00 199947978.8 1.1700E-05
A615Gr60 7.6973E+01 7.8490E+00 199947978.8 1.1700E-05

Table 2: Material Properties 03a - Steel Data

Table 2: Material Properties 03a - Steel Data
Fy Fu Final
Material
KN/m2 KN/m2 Slope
A36 248211.28 399895.96 -0.1
A992Fy50 344737.89 448159.26 -0.1

Table 3: Material Properties 03b - Concrete Data

Table 3: Material Properties 03b - Concrete Data
Fc eFc Final
Material
KN/m2 KN/m2 Slope
3000Psi 20684.27 20684.27 -0.1
4000Psi 27579.03 27579.03 -0.1

Table 4: Material Properties 03e - Rebar Data

Table 4: Material Properties 03e - Rebar Data
Fy Fu Final
Material
KN/m2 KN/m2 Slope
A615Gr40 275790.32 413685.47 -0.1
A615Gr60 413685.47 620528.21 -0.1

2. Section properties
SAP2000 Analysis Report This section provides section property information for objects used in the model.

2.1. Frames
Prepared by
RCF Table 5: Frame Section Properties 01 - General, Part 1 of 3
Table 5: Frame Section Properties 01 - General, Part 1 of 3
SectionName Material Shape t3 t2 tf tw t2b tfb
m m m m m m
Model Name: C_Raymundo_driveway.sdb C-800d 3000Psi Circle 0.8
W10X12 A36 I/Wide Flange 0.250698 0.100584 0.005334 0.004826 0.100584 0.005334
W10X15 A36 I/Wide Flange 0.253746 0.1016 0.006858 0.005842 0.1016 0.006858
W10X17 A36 I/Wide Flange 0.25654 0.101854 0.008382 0.006096 0.101854 0.008382
W10X19 A36 I/Wide Flange 0.25908 0.102108 0.010033 0.00635 0.102108 0.010033
W10X22 A36 I/Wide Flange 0.25908 0.14605 0.009144 0.006096 0.14605 0.009144
18 October 2018 W10X26 A36 I/Wide Flange 0.26162 0.146558 0.011176 0.006604 0.146558 0.011176
W10X30 A36 I/Wide Flange 0.2667 0.147574 0.012954 0.00762 0.147574 0.012954
W10X33 A36 I/Wide Flange 0.247142 0.202184 0.011049 0.007366 0.202184 0.011049
W10X39 A36 I/Wide Flange 0.251968 0.202946 0.013462 0.008001 0.202946 0.013462

Sandpiper Spices & Condiments Corporation Page 2 of 11

C_Raymundo_driveway.sdb SAP2000 v20.0.0 C_Raymundo_driveway.sdb SAP2000 v20.0.0
2. Section properties 18 October 2018 3. Load patterns 18 October 2018

Table 5: Frame Section Properties 01 - General, Part 1 of 3 Table 5: Frame Section Properties 01 - General, Part 3 of 3
SectionName Material Shape t3 t2 tf tw t2b tfb SectionName S33 S22 Z33 Z22 R33 R22
m m m m m m m3 m3 m3 m3 m m
W10X45 A36 I/Wide Flange 0.25654 0.203708 0.015748 0.00889 0.203708 0.015748 W10X49 0.000891 0.000306 0.00099 0.000464 0.110392 0.064688
W10X49 A36 I/Wide Flange 0.254 0.254 0.014224 0.008636 0.254 0.014224 W10X54 0.000983 0.000338 0.001091 0.000513 0.111231 0.064852
W10X54 A36 I/Wide Flange 0.25654 0.254 0.015621 0.009398 0.254 0.015621 W10X60 0.001096 0.000376 0.001222 0.000574 0.111487 0.065024
W10X60 A36 I/Wide Flange 0.25908 0.25654 0.017272 0.010668 0.25654 0.017272 W12X16 0.000281 0.000023 0.000329 0.000037 0.11878 0.019654
W12X16 A36 I/Wide Flange 0.3048 0.101346 0.006731 0.005588 0.101346 0.006731 W12X19 0.000349 0.000031 0.000405 0.000049 0.122709 0.020869
W12X19 A36 I/Wide Flange 0.30988 0.101854 0.00889 0.005969 0.101854 0.00889 W12X26 0.000548 0.000087 0.00061 0.000134 0.131165 0.038197
W12X26 A36 I/Wide Flange 0.30988 0.164846 0.009652 0.005842 0.164846 0.009652 W14X120 0.003119 0.001104 0.003474 0.001671 0.158813 0.095115
W14X120 A36 I/Wide Flange 0.3683 0.37338 0.023876 0.014986 0.37338 0.023876 W14X53 0.001276 0.000235 0.001427 0.000361 0.149579 0.048849
W14X53 A36 I/Wide Flange 0.35306 0.204724 0.016764 0.009398 0.204724 0.016764 W18X65 0.001906 0.000237 0.002179 0.000369 0.190112 0.043024
W18X65 A36 I/Wide Flange 0.46736 0.192786 0.01905 0.01143 0.192786 0.01905 W18X76 0.002395 0.000453 0.002671 0.000692 0.196158 0.066314
W18X76 A36 I/Wide Flange 0.46228 0.2794 0.017272 0.010795 0.2794 0.017272 W6X20 0.000219 0.000072 0.000246 0.00011 0.067455 0.038233
W6X20 A36 I/Wide Flange 0.15748 0.152908 0.009271 0.006604 0.152908 0.009271

Table 6: Frame Section Properties 02 - Concrete Column

Table 5: Frame Section Properties 01 - General, Part 2 of 3 Table 6: Frame Section Properties 02 - Concrete Column
Table 5: Frame Section Properties 01 - General, Part 2 of 3 Section Rebar Rebar Reinf Lat Cover Num Bar Bar SpacingC
SectionName Area TorsConst I33 I22 I23 AS2 AS3 Name MatL MatC Config Reinf m BarsCirc SizeL SizeC m
m2 m4 m4 m4 m4 m2 m2 C-800d A615Gr60 A615Gr40 Circular Spiral 0.04 25 16d 12d 0.075
C-800d 0.502655 0.040212 0.020106 0.020106 0. 0.452389 0.452389
W10X12 0.002284 2.277E-08 0.000022 9.074E-07 0. 0.00121 0.000894
W10X15 0.002845 4.329E-08 0.000029 1.203E-06 0. 0.001482 0.001161
W10X17 0.003219 6.493E-08 0.000034 1.482E-06 0. 0.001564 0.001423 3. Load patterns
W10X19 0.003626 9.698E-08 0.00004 1.786E-06 0. 0.001645 0.001707
W10X22 0.004187 9.948E-08 0.000049 4.745E-06 0. 0.001579 0.002226 This section provides loading information as applied to the model.
W10X26 0.00491 1.673E-07 0.00006 5.869E-06 0. 0.001728 0.00273
W10X30 0.005703 2.589E-07 0.000071 6.951E-06 0. 0.002032 0.003186 3.1. Definitions
W10X33 0.006265 2.427E-07 0.000071 0.000015 0. 0.00182 0.003723
W10X39 0.007419 4.062E-07 0.000087 0.000019 0. 0.002016 0.004553 Table 7: Load Pattern Definitions
W10X45 0.008581 6.285E-07 0.000103 0.000022 0. 0.002281 0.005347 Table 7: Load Pattern Definitions
W10X49 0.00929 5.786E-07 0.000113 0.000039 0. 0.002194 0.006021 Design Auto
LoadPat SelfWtMult
W10X54 0.010194 7.575E-07 0.000126 0.000043 0. 0.002411 0.006613 Type Load
W10X60 0.011419 1.032E-06 0.000142 0.000048 0. 0.002764 0.007385 Dead Load Dead 1.
W12X16 0.003039 4.287E-08 0.000043 1.174E-06 0. 0.001703 0.001137 Utilities Super Dead 0.
W12X19 0.003594 7.492E-08 0.000054 1.565E-06 0. 0.00185 0.001509 Roofing Super Dead 0.
W12X26 0.004935 1.249E-07 0.000085 7.201E-06 0. 0.00181 0.002652 Lr Roof Live 0.
W14X120 0.022774 3.900E-06 0.000574 0.000206 0. 0.005519 0.014858 WindX Wind 0. ASCE7-10
W14X53 0.010064 8.075E-07 0.000225 0.000024 0. 0.003318 0.00572 WindY Wind 0. ASCE7-10
W18X65 0.012323 1.136E-06 0.000445 0.000023 0. 0.005342 0.006121 EQX Quake 0. UBC97
W18X76 0.014387 1.178E-06 0.000554 0.000063 0. 0.00499 0.008043 EQY Quake 0. UBC97
W6X20 0.003787 9.990E-08 0.000017 5.536E-06 0. 0.00104 0.002363

3.2. Auto wind loading

Table 5: Frame Section Properties 01 - General, Part 3 of 3
Table 5: Frame Section Properties 01 - General, Part 3 of 3
SectionName S33 S22 Z33 Z22 R33 R22 Table 8: Auto Wind - ASCE7-10, Part 1 of 2
m3 m3 m3 m3 m m Table 8: Auto Wind - ASCE7-10, Part 1 of 2
C-800d 0.050265 0.050265 0.085333 0.085333 0.2 0.2 Angle MaxZ MinZ WindSpeed Gust Solid
LoadPat Exposure I Kzt Kd
W10X12 0.000179 0.000018 0.000206 0.000029 0.09902 0.019932 Degrees m m mph Factor Ratio
W10X15 0.000226 0.000024 0.000262 0.000038 0.100398 0.020562 WindY 90. 9.6444 0. 155. B 1. 1. 0.85 0.85 0.2
W10X17 0.000266 0.000029 0.000306 0.000046 0.102902 0.021454 WindX 0. 155. B 1. 1. 0.85 0.85 0.2
W10X19 0.000309 0.000035 0.000354 0.000055 0.105143 0.022192
W10X22 0.000379 0.000065 0.000426 0.0001 0.108306 0.033664
W10X26 0.000458 0.00008 0.000513 0.000123 0.11049 0.034574
W10X30 0.000531 0.000094 0.0006 0.000145 0.111386 0.034911
W10X33 0.000576 0.000151 0.000636 0.000229 0.106591 0.049313
W10X39 0.000691 0.000185 0.000767 0.000282 0.108282 0.050245
W10X45 0.000805 0.000218 0.0009 0.000333 0.109682 0.050895

Sandpiper Spices & Condiments Corporation Page 3 of 11 Sandpiper Spices & Condiments Corporation Page 4 of 11
C_Raymundo_driveway.sdb SAP2000 v20.0.0 C_Raymundo_driveway.sdb SAP2000 v20.0.0
4. Load cases 18 October 2018 5. Load combinations 18 October 2018

3.3. Auto seismic loading Table 11: Combination Definitions

Combo Combo Case Scale
Name Type Name Factor
Table 9: Auto Seismic - UBC97, Part 1 of 2 USD203 Roofing 1.2
USD204 Linear Add Dead Load 1.2
Table 9: Auto Seismic - UBC97, Part 1 of 3
USD204 WindX -1.
Percent Soil Source SourceDist
LoadPat Dir Ct R Z Ca Cv USD204 Utilities 1.2
Ecc Type Type km
USD204 Roofing 1.2
EQX X 0.05 0.035 8.5 SD 0.4 0.66 1.28 A 2.
USD205 Linear Add Dead Load 1.2
EQY Y 0.05 0.035 8.5 SD 0.4 0.66 1.28 A 2.
USD205 WindY 1.
USD205 Roofing 1.2
USD205 Utilities 1.2
Table 9: Auto Seismic - UBC97, Part 2 of 2 USD206 Linear Add Dead Load 1.2
TUsed WeightUsed BaseShear FtUsed USD206 WindY -1.
LoadPat Na Nv I USD206 Utilities 1.2
Sec KN KN KN
EQX 1.5 2. 1. 0.3789 304.49 59.107 0. USD206 Roofing 1.2
EQY 1.5 2. 1. 0.3402 304.49 59.107 0. USD207 Linear Add Dead Load 1.2
USD207 Lr 0.5
USD207 WindX 1.
USD207 Utilities 1.2
4. Load cases USD207 Roofing 1.2
USD208 Linear Add Dead Load 1.2
This section provides load case information. USD208 Lr 0.5
USD208 WindX -1.
USD208 Utilities 1.2
4.1. Definitions USD208 Roofing 1.2
USD209 Linear Add Dead Load 1.2
Table 10: Load Case Definitions, Part 1 of 2 USD209 Lr 0.5
Table 10: Load Case Definitions, Part 1 of 2 USD209 WindY 1.
Case Type Initial Modal Base Mass DesActOpt USD209 Utilities 1.2
Cond Case Case Source USD209 Roofing 1.2
Dead Load LinStatic Zero Prog Det USD210 Linear Add Dead Load 1.2
MODAL LinModal Zero Prog Det USD210 Lr 0.5
Utilities LinStatic Zero Prog Det USD210 WindY -1.
Roofing LinStatic Zero Prog Det USD210 Utilities 1.2
Lr LinStatic Zero Prog Det USD210 Roofing 1.2
WindX LinStatic Zero Prog Det USD211 Linear Add Dead Load 1.2
WindY LinStatic Zero Prog Det USD211 Lr 1.6
EQX LinStatic Zero Prog Det USD211 WindX 0.5
EQY LinStatic Zero Prog Det USD211 Utilities 1.2
USD211 Roofing 1.2
USD212 Linear Add Dead Load 1.2
USD212 Lr 1.6
5. Load combinations USD212 WindX -0.5
USD212 Utilities 1.2
This section provides load combination information. USD212 Roofing 1.2
USD213 Linear Add Dead Load 1.2
Table 11: Combination Definitions USD213 Lr 1.6
Table 11: Combination Definitions USD213 WindY 0.5
Combo Combo Case Scale USD213 Utilities 1.2
Name Type Name Factor USD213 Roofing 1.2
USD201 Linear Add Dead Load 1.4 USD214 Linear Add Dead Load 1.2
USD201 Utilities 1.4 USD214 Lr 1.6
USD201 Roofing 1.4 USD214 WindY -0.5
USD202 Linear Add Dead Load 1.2 USD214 Utilities 1.2
USD202 Lr 1.6 USD214 Roofing 1.2
USD202 Utilities 1.2 USD215 Linear Add Dead Load 0.9
USD202 Roofing 1.2 USD215 WindX 1.
USD203 Linear Add Dead Load 1.2 USD215 Utilities 0.9
USD203 WindX 1. USD215 Roofing 0.9
USD203 Utilities 1.2 USD216 Linear Add Dead Load 0.9
USD216 WindX -1.

Sandpiper Spices & Condiments Corporation Page 5 of 11 Sandpiper Spices & Condiments Corporation Page 6 of 11
C_Raymundo_driveway.sdb SAP2000 v20.0.0 C_Raymundo_driveway.sdb SAP2000 v20.0.0
5. Load combinations 18 October 2018 6. Design preferences 18 October 2018

Table 11: Combination Definitions

Combo Combo Case Scale
6. Design preferences
Name Type Name Factor This section provides the design preferences for each type of design, which typically include material reduction
USD216 Utilities 0.9 factors, framing type, stress ratio limit, deflection limits, and other code specific items.
USD216 Roofing 0.9
USD217 Linear Add Dead Load 0.9
USD217 WindY 1.
6.1. Steel design
USD217 Utilities 0.9
Table 12: Preferences - Steel Design - AISC 360-10, Part 1 of 4
USD217 Roofing 0.9
USD218 Linear Add Dead Load 0.9 Table 12: Preferences - Steel Design - AISC 360-10, Part 1 of 4
USD218 WindY -1. Frame PatLLF SRatio MaxIter SDC Seis Seis Imp
THDesign
USD218 Utilities 0.9 Type Limit Code Load Factor
USD218 Roofing 0.9 Envelopes SMF 0.75 0.95 1 D Yes Yes 1.
DEF1 Linear Add Dead Load 1.
DEF1 Utilities 1.
DEF1 Roofing 1. Table 12: Preferences - Steel Design - AISC 360-10, Part 2 of 4
USD219 Linear Add Dead Load 1.2
Table 12: Preferences - Steel Design - AISC 360-10, Part 2 of 4
USD219 Roofing 1.2
System System System System
USD219 Utilities 1.2 Omega0 Provision AMethod SOMethod SRMethod
Rho Sds R Cd
USD219 Lr 1.
Effective General 2nd
USD219 EQX 1. 1. 0.5 8. 5.5 3. LRFD Tau-b Fixed
Length Order
USD220 Linear Add Dead Load 1.2
USD220 Roofing 1.2
USD220 Utilities 1.2
USD220 Lr 1.
Table 12: Preferences - Steel Design - AISC 360-10, Part 3 of 4
USD220 EQX -1. Table 12: Preferences - Steel Design - AISC 360-10, Part 3 of 4
USD221 Linear Add Dead Load 1.2 PhiV Plug
NLCoeff PhiB PhiC PhiTY PhiTF PhiV PhiVT
USD221 Roofing 1.2 RolledI Weld
USD221 Utilities 1.2 0.002 0.9 0.9 0.9 0.75 0.9 1. 0.9 Yes
USD221 Lr 1.
USD221 EQY 1.
USD222 Linear Add Dead Load 1.2 Table 12: Preferences - Steel Design - AISC 360-10, Part 4 of 4
USD222 Roofing 1.2
Table 12: Preferences - Steel Design - AISC 360-10, Part 4 of 4
USD222 Utilities 1.2
USD222 Lr 1. HSS HSS Check DLRat SDLAnd LLRat Total NetRat
USD222 EQY -1. Welding ReduceT Defl LLRat Rat
USD223 Linear Add Dead Load 0.9 ERW No No 120. 120. 360. 240. 240.
USD223 Roofing 0.9
USD223 Utilities 0.9
USD223 EQX 1. 6.2. Concrete design
USD224 Linear Add Dead Load 0.9
USD224 Roofing 0.9 Table 13: Preferences - Concrete Design - ACI 318-14, Part 1 of 2
USD224 Utilities 0.9
Table 13: Preferences - Concrete Design - ACI 318-14, Part 1 of 2
USD224 EQX -1.
TH Num Num Min UFLimit Seis
USD225 Linear Add Dead Load 0.9 PatLLF Rho Sds
Design Curves Points Eccen Cat
USD225 Roofing 0.9
Envelopes 24 11 Yes 0.75 0.95 D 1. 0.5
USD225 Utilities 0.9
USD225 EQY 1.
USD226 Linear Add Dead Load 0.9
USD226 Roofing 0.9 Table 14: Preferences - Concrete Design - ACI 318-14, Part 2 of 2
USD226 Utilities 0.9 Table 14: Preferences - Concrete Design - ACI 318-14, Part 2 of 2
USD226 EQY -1.
PhiT PhiCTied PhiCSpiral PhiV PhiVSeismic PhiVJoint

0.9 0.65 0.75 0.75 0.6 0.85

Sandpiper Spices & Condiments Corporation Page 7 of 11 Sandpiper Spices & Condiments Corporation Page 8 of 11
C_Raymundo_driveway.sdb SAP2000 v20.0.0 C_Raymundo_driveway.sdb SAP2000 v20.0.0
7. Design summary 18 October 2018 7. Design summary 18 October 2018

Table 15: Steel Design 1 - Summary Data - AISC 360-10

7. Design summary Design Design Ratio Combo Location
Frame Status Ratio
This section provides the design summary for each type of design, which highlights the controlling Sect Type Type m
demand/capacity ratio and it's associated combination and location in each member. 162 W12X26 Brace No Messages 0.021896 PMM USD209 1.16738
163 W12X26 Brace No Messages 0.023747 PMM USD209 1.16738
164 W12X26 Brace No Messages 0.026004 PMM USD205 1.16738
7.1. Steel design 165 W12X26 Brace No Messages 0.022289 PMM USD205 1.16738
Table 15: Steel Design 1 - Summary Data - AISC 360-10 166 W12X26 Brace No Messages 0.024644 PMM USD205 1.16738
167 W12X26 Brace No Messages 0.027182 PMM USD205 1.16738
Table 15: Steel Design 1 - Summary Data - AISC 360-10 168 W12X26 Beam No Messages 0.277685 PMM USD210 0.
Design Design Ratio Combo Location 169 W12X26 Beam No Messages 0.277281 PMM USD210 0.
Frame Status Ratio
Sect Type Type m 170 W12X26 Beam No Messages 0.279477 PMM USD210 0.
95 W14X120 Column No Messages 0.380607 PMM USD207 1.6 171 W18X76 Beam No Messages 0.084363 PMM USD210 0.
97 W14X120 Column No Messages 0.35406 PMM USD210 1.6 172 W12X26 Beam No Messages 0.267105 PMM USD210 0.
98 W18X76 Beam No Messages 0.146935 PMM USD210 0. 173 W12X26 Beam No Messages 0.237523 PMM USD210 0.
99 W18X76 Beam No Messages 0.287614 PMM USD210 0. 174 W12X26 Beam No Messages 0.216025 PMM USD204 1.285
100 W18X76 Brace No Messages 0.534814 PMM USD208 7.00427 175 W12X26 Brace No Messages 0.020551 PMM USD209 1.16738
103 W18X76 Brace No Messages 0.532973 PMM USD214 7.00427 176 W12X26 Brace No Messages 0.020865 PMM USD209 1.16738
106 W18X76 Brace No Messages 0.68461 PMM USD208 7.00427 177 W12X26 Brace No Messages 0.021336 PMM USD209 1.16738
109 W18X76 Brace No Messages 0.684118 PMM USD213 7.00427 178 W12X26 Brace No Messages 0.020663 PMM USD209 1.16738
112 W18X76 Brace No Messages 0.610616 PMM USD208 7.00427 179 W12X26 Brace No Messages 0.021156 PMM USD209 1.16738
115 W18X76 Brace No Messages 0.601977 PMM USD210 7.00427 180 W12X26 Brace No Messages 0.021725 PMM USD209 1.16738
118 W18X76 Brace No Messages 0.626334 PMM USD208 7.00427 181 W12X26 Beam No Messages 0.331704 PMM USD208 2.53
121 W18X76 Brace No Messages 0.804079 PMM USD210 7.00427 182 W12X26 Beam No Messages 0.282623 PMM USD213 2.53
124 W12X26 Beam No Messages 0.310861 PMM USD214 6. 183 W12X26 Beam No Messages 0.291475 PMM USD209 2.53
125 W12X26 Beam No Messages 0.422648 PMM USD216 6. 184 W18X76 Beam No Messages 0.192171 PMM USD208 2.53
126 W12X26 Beam No Messages 0.316953 PMM USD213 6. 185 W12X26 Beam No Messages 0.278943 PMM USD213 2.53
127 W12X26 Beam No Messages 0.298037 PMM USD211 6. 186 W12X26 Beam No Messages 0.274126 PMM USD213 2.53
128 W12X26 Beam No Messages 0.297771 PMM USD211 6. 187 W12X26 Beam No Messages 0.390076 PMM USD208 2.53
129 W12X26 Beam No Messages 0.368455 PMM USD216 6. 3 W10X19 Column No Messages 0.670288 PMM USD208 1.6
130 W12X26 Beam No Messages 0.431341 PMM USD216 0. 5 W10X26 Column No Messages 0.454684 PMM USD207 2.68148
131 W12X26 Beam No Messages 0.309386 PMM USD214 0. 8 W10X19 Beam No Messages 0.300601 PMM USD204 3.
132 W12X26 Beam No Messages 0.316122 PMM USD214 0. 9 W10X19 Beam No Messages 0.274506 PMM USD207 3.
133 W12X26 Beam No Messages 0.317524 PMM USD211 0. 10 W10X19 Beam No Messages 0.294806 PMM USD207 3.
134 W12X26 Beam No Messages 0.325508 PMM USD211 0. 11 W10X19 Beam No Messages 0.253862 PMM USD207 3.
135 W12X26 Beam No Messages 0.354366 PMM USD208 0. 12 W10X26 Column No Messages 0.651555 PMM USD207 4.28148
136 W12X26 Brace No Messages 0.021648 PMM USD205 1.16738 15 W10X26 Column No Messages 0.717396 PMM USD208 0.
137 W12X26 Brace No Messages 0.022373 PMM USD205 1.16738 20 W6X20 Brace No Messages 0.051206 PMM USD207 4.02372
138 W12X26 Brace No Messages 0.023172 PMM USD205 1.16738 21 W6X20 Brace No Messages 0.228757 PMM USD208 4.02372
139 W12X26 Brace No Messages 0.022018 PMM USD210 1.16738 22 W6X20 Brace No Messages 0.042343 PMM USD210 0.
140 W12X26 Brace No Messages 0.022748 PMM USD205 1.16738 23 W6X20 Brace No Messages 0.212664 PMM USD208 4.02372
141 W12X26 Brace No Messages 0.023615 PMM USD205 1.16738 24 W6X20 Brace No Messages 0.210804 PMM USD208 0.
142 W12X26 Beam No Messages 0.300017 PMM USD208 0. 25 W6X20 Brace No Messages 0.039337 PMM USD217 4.02372
143 W12X26 Beam No Messages 0.287701 PMM USD210 0. 26 W6X20 Brace No Messages 0.227078 PMM USD208 0.
144 W12X26 Beam No Messages 0.294846 PMM USD210 0. 27 W6X20 Brace No Messages 0.031095 PMM USD208 2.01186
145 W18X76 Beam No Messages 0.175785 PMM USD208 0. 2 W14X120 Column No Messages 0.345737 PMM USD209 1.6
146 W12X26 Beam No Messages 0.286514 PMM USD210 0.
147 W12X26 Beam No Messages 0.279573 PMM USD210 0.
148 W12X26 Beam No Messages 0.371844 PMM USD208 0.
149 W12X26 Brace No Messages 0.02182 PMM USD206 1.16738 7.2. Concrete design
150 W12X26 Brace No Messages 0.023852 PMM USD206 1.16738
151 W12X26 Brace No Messages 0.026159 PMM USD206 1.16738 Table 16: Concrete Design 1 - Column Summary Data - ACI 318-14, Part 1 of 2
152 W12X26 Brace No Messages 0.022822 PMM USD209 1.16738 Table 16: Concrete Design 1 - Column Summary Data - ACI 318-14, Part 1 of 2
153 W12X26 Brace No Messages 0.024846 PMM USD209 1.16738 Frame Design Design Design Status Location PMM
154 W12X26 Brace No Messages 0.027229 PMM USD206 1.16738 Sect Type Opt m Combo
155 W12X26 Beam No Messages 0.200144 PMM USD208 1.36 188 C-800d Column Design No Messages 0. USD201
156 W12X26 Beam No Messages 0.279153 PMM USD209 1.36 188 C-800d Column Design No Messages 3.1 USD201
157 W12X26 Beam No Messages 0.291515 PMM USD209 1.36 188 C-800d Column Design No Messages 6.2 USD201
158 W18X76 Beam No Messages 0.086216 PMM USD210 1.36 189 C-800d Column Design No Messages 0. USD201
159 W12X26 Beam No Messages 0.288978 PMM USD209 1.36 189 C-800d Column Design No Messages 3.1 USD201
160 W12X26 Beam No Messages 0.277377 PMM USD209 1.36 189 C-800d Column Design No Messages 6.2 USD208
161 W12X26 Beam No Messages 0.165672 PMM USD208 1.36 190 C-800d Column Design No Messages 0. USD201

Sandpiper Spices & Condiments Corporation Page 9 of 11 Sandpiper Spices & Condiments Corporation Page 10 of 11
C_Raymundo_driveway.sdb SAP2000 v20.0.0
7. Design summary 18 October 2018

Table 16: Concrete Design 1 - Column Summary Data - ACI 318-14, Part 1 of 2
Frame Design Design Design Status Location PMM
Sect Type Opt m Combo
190 C-800d Column Design No Messages 3.9 USD201
190 C-800d Column Design No Messages 7.8 USD201

Table 16: Concrete Design 1 - Column Summary Data - ACI 318-14, Part 2 of 2
Table 16: Concrete Design 1 - Column Summary Data - ACI 318-14, Part 2 of 2
Frame PMMArea PMM VMaj VMajRebar VMin VMinRebar
m2 Ratio Combo m2/m Combo m2/m
188 0.005027 USD219 0.000152 USD225 0.000188
188 0.005027 USD219 0.000152 USD225 0.000188
188 0.005027 USD219 0.000152 USD225 0.000188
189 0.005027 USD220 0.000229 USD221 0.000184
189 0.005027 USD220 0.000229 USD221 0.000184
189 0.006283 USD220 0.000229 USD221 0.000184
190 0.005027 USD224 0.000187 USD221 0.000125
190 0.005027 USD224 0.000187 USD221 0.000125
190 0.005027 USD224 0.000187 USD221 0.000125

Sandpiper Spices & Condiments Corporation Page 11 of 11

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F1 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-08/UBC 97
+Y
Input Data:
3 2
Material Properties:
Conc. Comp. Strength, fc'= 20.70 Mpa L/2
Reinf. Yeild Strength, fy= 275.00 Mpa
Concrete Unit Wt., γc= 23.54 kN/m^3
Lcy +X
B
Soil Properties:
Allow. Soil Pressure, SBC = 72.00 kPa Lcx B/2
Soil Unit Weight, γs = 18.00 kPa
Depth of Trench, D = 1.50 m
4 L 1
Footing Info:
Footing Length, L = 2300 mm
Footing Plan
Footing Width, B = 2300 mm
Footing Thickness, T = 600 mm
Clear Cover, Cc = 75 mm
Reinforcing Bar Diameter = 20 mm Pu

Column Info: Interior

Column Length, Lcx= 710 mm
Q
Column Width, Lcy= 710 mm
Location along X= 0 mm
Location along Y= 0 mm Lcx h
Ph
Loading Data: D
Service Dead Load, D= 296.90 kN (Working) T
Service Live Load, L= 61.71 kN (Working)
Service Surcharge, Q= 0.00 kPa
q
Earthquake Axial Load, Eh= -8.29 kN (Working)
Wind Axial Load, W = -108.14 kN (Working) L

Nomenclature
Seismic Parameters:
Rho, ρ = 1.00 (from ETABS, 1.0 default)
Seismic Coefficient, Ca = (Table 16-Q UBC'97)
Importance Factor, I = 1.00 (Table 16-K UBC'97)
Therefore, E = -8.29 kN (Ultimate)
Therefore, E = -8.29 kN (Service)

Where:
E = ρEh + 0.50CaID ===> Ultimate
E = ρEh ===> Service

Service Load Combinations:

ASD101: D + L = 358.61 kN (governs)
ASD102: D + W = 188.76 kN
ASD103: D + E/1.4 = 290.97 kN
ASD104: D + 0.75(L + E/1.4) = 338.74 kN (neglect)
ASD105: 0.60D + E/1.4 = 172.22 kN (neglect)
ASD106: D + L + E/1.4 = 352.68 kN (neglect)
ASD107: D + 0.75(L +W) = 262.08 kN (neglect)
ASD108: 0.60D + W = 70.00 kN (neglect)
ASD109: D + L + W = 250.47 kN (neglect)

F1_driveway Page 1 of 6 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F1 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-08/UBC 97
Ultimate Load Combinations:
USD201: 1.4D = 415.66 kN
USD202: 1.2D + 1.6L = 455.01 kN (governs)
USD203: 1.2D + 0.80W = 269.77 kN
USD204: 0.90D + 1.6W = 94.18 kN
USD205: 1.2D + 1.6W + 0.5L = 214.11 kN
USD206: 1.2D + 1.0E + 0.5L = 378.84 kN
USD207: 0.90D + 1.0E = 258.92 kN

Design Procedure:

Check Soil Bearing Capacity:

Column Working Load, Rv = 358.61 kN
Working Bearing Pressure, qv = 67.79 kPa
Demand-Capacity Ratio, D/C = 0.94 < 1, …OK (Footing is adequate to carry the loadings)

Applied Ultimate Soil Bearing Pressure:

Ultimate Axial Load, Pu = 455.01 kN
Ultimate Bearing Pressure, qu = 86.01 kPa

Design Checks: c1+d

1. Wide-beam action along L-Direction
Vu = qs x tributary area
= 53.41 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 700.46 kN > Vu = 53.41 kN O.K.
2. Wide-beam action along B-Direction
Vu = qs x tributary area bw c2+d c2
= 53.41 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 700.46 kN > Vu = 53.41 kN O.K.
2. Two-way action (Punching Shear)
Vu = qs x tributary area
=307.40 kN
φVc = φ0.17(1+(2/β))λ√fc'bod (ACI 318-08 Eq. (11-31)) d
= 4,513.39 kN
φVc = φ0.083(((αsd)/bo)+2)√fc'bod (ACI 318-08 Eq. (11-32)) Tributary area for two-way action shear
= 4,591.57 kN
φVc = φ0.33λfc'^1/2*bod (ACI 318-08 Eq. (11-33)) Tributary area for wide-beam action shear
= 2,920.43 kN governs> Vu = 307.40 kN O.K.

Design for Reinforcement:

1. For L-Direction 2. For B-Direction
Mu = 62.52 kN-m Mu = 62.52 kN-m
a= 17.08 mm a= 17.08 mm
β1 = 0.85 (ACI 318-08 Sec.10.2.7.3) β1 = 0.85 (ACI 318-08 Sec.10.2.7.3)
c= 20.09 mm c= 20.09 mm
εt = 0.0754 >= 0.004, Tension-controlled εt = 0.0754 >= 0.004, Tension-controlled
φ= 0.90 (ACI 318-08 Sec. 9.3.2) φ= 0.90 (ACI 318-08 Sec. 9.3.2)
Rn = 0.11 Mpa Rn = 0.11 Mpa
ρ = 0.00040 ρ = 0.00040
ρ(gross area) = 0.00035 < rho(min), use rho(min) ρ(gross area) = 0.00035 < rho(min), use rho(min)
ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4) ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4)
As = 2415.00 mm^2 As = 2415.00 mm^2

F1_driveway Page 2 of 6 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F1 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-08/UBC 97

Critical Section of Bending Along L-Direction Critical Section for Bending Along B-Direction

Design Summary:

Note: Maximum bar spacing (s), must not exceed 450mm (ACI 318-08 Sec.15.10.4).

Footing Plan

Footing Size:
Use 2.30 m x 2.30 m x 0.60 m Footing Dimension.
Reinforcements:
Use 8 pcs 20 mm diam. RSB eachway.

F1_driveway Page 3 of 6 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F2 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97
+Y
Input Data:
3 2
Material Properties:
Conc. Comp. Strength, fc'= 20.70 Mpa L/2
Reinf. Yeild Strength, fy= 275.00 Mpa
Concrete Unit Wt., γc= 23.54 kN/m^3
Lcy +X
B
Soil Properties:
Allow. Soil Pressure, SBC = 72.00 kPa Lcx B/2
Soil Unit Weight, γs = 18.00 kPa
Depth of Trench, D = 1.50 m
4 L 1
Footing Info:
Footing Length, L = 1200 mm
Footing Plan
Footing Width, B = 800 mm
Footing Thickness, T = 300 mm
Clear Cover, Cc = 75 mm
Reinforcing Bar Diameter = 16 mm Pu

Column Info: Edge

Column Length, Lcx= 300 mm
Q
Column Width, Lcy= 300 mm
Location along X= 0 mm
Location along Y= 250 mm Lcx h
Ph
Loading Data: D
Service Dead Load, D= 22.64 kN (Working) T
Service Live Load, L= 3.06 kN (Working)
Service Surcharge, Q= kPa
q
Earthquake Axial Load, Eh= 7.90 kN (Working)
Wind Axial Load, W = 30.04 kN (Working) L

Nomenclature
Seismic Parameters:
Rho, ρ = 1.00 (from ETABS, 1.0 default)
Seismic Coefficient, Ca = (Table 16-Q UBC'97)
Importance Factor, I = 1.00 (Table 16-K UBC'97)
Therefore, E = 7.90 kN (Ultimate)
Therefore, E = 7.90 kN (Service)

Where:
E = ρEh + 0.50CaID ===> Ultimate
E = ρEh ===> Service

Service Load Combinations:

ASD101: D + L = 25.69 kN (Transient loads govern, neglect)
ASD102: D + W = 52.67 kN (Transient loads govern, neglect)
ASD103: D + E/1.4 = 28.28 kN (Transient loads govern, neglect)
ASD104: D + 0.75(L + E/1.4) = 29.16 kN
ASD105: 0.60D + E/1.4 = 19.22 kN
ASD106: D + L + E/1.4 = 31.33 kN
ASD107: D + 0.75(L +W) = 47.45 kN
ASD108: 0.60D + W = 43.62 kN
ASD109: D + L + W = 55.73 kN (governs)

F2_driveway Page 4 of 6 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F2 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97
Ultimate Load Combinations:
USD201: 1.4D = 31.69 kN
USD202: 1.2D + 1.6L = 32.05 kN
USD203: 1.2D + 0.80W = 51.19 kN
USD204: 0.90D + 1.6W = 68.43 kN
USD205: 1.2D + 1.6W + 0.5L = 76.75 kN (governs)
USD206: 1.2D + 1.0E + 0.5L = 36.59 kN
USD207: 0.90D + 1.0E = 28.27 kN

Design Procedure:

Check Soil Bearing Capacity:

Column Working Load, Rv = 55.73 kN
Working Bearing Pressure, qv = 58.05 kPa
Demand-Capacity Ratio, D/C = 0.81 < 1, …OK (Footing is adequate to carry the loadings)

Applied Ultimate Soil Bearing Pressure:

Ultimate Axial Load, Pu = 76.75 kN
Ultimate Bearing Pressure, qu = 79.94 kPa

Design Checks: c1+d

1. Wide-beam action along L-Direction
Vu = qs x tributary area
= 14.39 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 104.42 kN > Vu = 14.39 kN O.K.
2. Wide-beam action along B-Direction
Vu = qs x tributary area bw c2+d c2
= 2.40 kN
φVc = φ0.17λ√fc'bwd (ACI 318-08 Eq. (11-3))
= 156.62 kN > Vu = 2.40 kN O.K.
2. Two-way action (Punching Shear)
Vu = qs x tributary area
=55.16 kN
φVc = φ0.17(1+(2/β))λ√fc'bod (ACI 318-08 Eq. (11-31)) d
= 822.28 kN
φVc = φ0.083(((αsd)/bo)+2)√fc'bod (ACI 318-08 Eq. (11-32)) Tributary area for two-way action shear
= 697.78 kN
φVc = φ0.33λfc'^1/2*bod (ACI 318-08 Eq. (11-33)) Tributary area for wide-beam action shear
= 532.06 kN governs > Vu = 55.16 kN O.K.

Design for Reinforcement:

1. For L-Direction 2. For B-Direction
Mu = 6.48 kN-m Mu = 11.99 kN-m
a= 7.86 mm a= 19.64 mm
β1 = 0.85 (ACI 318-08 Sec.10.2.7.3) β1 = 0.85 (ACI 318-08 Sec.10.2.7.3)
c= 9.24 mm c= 23.11 mm
εt = 0.0700 >= 0.004, Tension-controlled εt = 0.0262 >= 0.004, Tension-controlled
φ= 0.90 (ACI 318-08 Sec. 9.3.2) φ= 0.90 (ACI 318-08 Sec. 9.3.2)
Rn = 0.18 Mpa Rn = 0.22 Mpa
ρ = 0.00065 ρ = 0.00080
ρ(gross area) = 0.00049 < rho(min), use rho(min) ρ(gross area) = 0.00060 < rho(min), use rho(min)
ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4) ρ(min) = 0.00200 (ACI 318-08 Sec.15.10.4)
As = 360.00 mm^2 As = 540.00 mm^2

F2_driveway Page 5 of 6 Developed by: Engr. Richard C. Fernandez

 Project Name: PROPOSED EXPANSION OF NORTH SOUTH REALTY
Client: SANDPIPER SPICES & CONDIMENTS CORPORATION
Location: 255 C. RAYMUNDO, PASIG CITY
Designed by: RCF Checked by:
Subject: F2 Date: 15-Oct-18
Design of Concentrically Loaded Isolated Footing According to ACI 318-14/UBC 97

Critical Section of Bending Along L-Direction Critical Section for Bending Along B-Direction

Design Summary:

Note: Maximum bar spacing (s), must not exceed 450mm (ACI 318-08 Sec.15.10.4).

Footing Plan

Footing Size:
Use 0.80 m x 1.20 m x 0.30 m Footing Dimension.
Reinforcements:
Use 3 pcs 16 mm diam. RSB for Long Direction.
Use 5 pcs 16 mm diam. RSB for Short Direction

F2_driveway Page 6 of 6 Developed by: Engr. Richard C. Fernandez
